SVOLT 8.32kWh 25.6V 325Ah LiFePO₄ Lithium Battery
SVOLT 8.32kWh 25.6V 325Ah LiFePO₄ Lithium Battery
Please note that the stock quantities displayed are for our warehouse. Please confirm stock on hand directly with us before collecting your order.
Low stock: 10 left
Couldn't load pickup availability
Product Description
The SVOLT LFP-8.32kWh is a high-capacity 25.6V wall-mounted lithium battery designed for compatible 24V solar, backup and off-grid energy systems.
With 8.32kWh of nominal energy, 325Ah capacity and LiFePO₄ chemistry, it provides substantial low-voltage battery storage in a single unit. The battery includes an integrated BMS, touch display, optional Bluetooth monitoring and supports up to 16 batteries in parallel for larger energy-storage systems.
Key Features
8.32kWh nominal energy
325Ah rated capacity
25.6V nominal voltage
LiFePO₄ battery chemistry
Wall-mounted installation
Built-in Battery Management System
Touchable display screen
Optional Bluetooth APP monitoring
More than 6,000 stated cycles
Up to 16 batteries in parallel
Maximum continuous charge current: 150A
Maximum continuous discharge current: 150A
Peak discharge current: 200A for 100ms
Round-trip efficiency above 95%
IEC 62619, CE and UN38.3 certification
High-Capacity 24V Battery Storage
The battery operates at a nominal 25.6V with a rated capacity of 325Ah, providing 8.32kWh of nominal energy storage.
This makes it suitable for compatible 24V-class inverter systems requiring greater storage capacity without using several smaller batteries.
Battery Performance
The technical specifications state:
Operating voltage range: 21.6V to 29.2V
Recommended charge voltage: 28V
Maximum charge voltage: 29.2V
Maximum continuous charge current: 150A
Recommended discharge voltage: 23.2V
Maximum discharging voltage: 21.6V
Maximum continuous discharge current: 150A
Peak discharge current: 200A for 100ms
Expandable Battery System
Up to 16 compatible batteries can be connected in parallel.
Based on the stated 8.32kWh capacity per battery, this allows a maximum nominal storage capacity of approximately 133.12kWh when all 16 units are used.
Series connection is not permitted.
Integrated Battery Management
The battery includes a built-in BMS to assist with monitoring and safe battery operation.
The datasheet also specifies:
Internal resistance: Less than 25mΩ
Round-trip efficiency: Greater than 95%
Self-discharge: Less than 3% per month
Touch Display and Optional Bluetooth
The unit includes a touch display for local battery monitoring.
Bluetooth APP functionality is listed as optional, providing an additional monitoring option where the required functionality is included.
Technical Specifications
Brand: SVOLT
Model: LFP-8.32kWh
Battery chemistry: LiFePO₄
Nominal energy: 8.32kWh
Nominal voltage: 25.6V
Nominal capacity: 325Ah
Installation type: Wall mounted
Dimensions: 650 × 570 × 200mm
Approximate weight: 65kg
Terminal type: Screw terminal
Case material: SPCC
Built-in BMS: Yes
Internal resistance: Less than 25mΩ
Round-trip efficiency: Greater than 95%
Self-discharge: Less than 3% per month
Maximum parallel units: 16
Series connection: Not allowed
Cycle life: More than 6,000 cycles at 1/3C charge/discharge
Discharge temperature: -20°C to 60°C
Charge temperature: 0°C to 55°C
Storage temperature: 0°C to 30°C
Bluetooth APP: Optional
Display: Touchable display screen
Safety certification: IEC62619, CE, UN38.3
Recommended Applications
The SVOLT 8.32kWh battery is suitable for:
Residential backup systems
Compatible 24V solar systems
Off-grid installations
UPS applications
Small commercial energy storage
Solar self-consumption
Larger expandable battery banks
Important Compatibility Notice
This battery is designed for compatible 24V-class inverter systems.
The inverter’s battery voltage range, charging settings, current limits and communication requirements must be confirmed before installation.
Series connection is not permitted according to the supplied datasheet.
Warranty and Installation Requirements
Product warranty: 5 years
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour
A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system
The installation must be compliant with SANS 10142 and all its parts
Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman or master electrician installing the unit, can be rejected and will render the warranty claim null and void.
