5KVA 48V GROWATT Hybrid Inverter + WIFI Logger

5KVA / 5000W Growatt SPF 5000 Hybrid Inverter 48V + WIFI

Description

The Growatt SPF 5000 Hybrid Inverter is a highly adaptable hybrid inverter designed for residential and commercial solar systems. With its maximum PV input voltage of 450VDC, this inverter can effectively harness solar power and convert it into usable energy. It offers the flexibility of operating with or without a battery, allowing you to choose the setup that best suits your energy needs.

One of the key features of the Growatt SPF 5000 Hybrid Inverter is its integrated MPPT charge controller. This controller optimizes the charging and discharging of the battery, prolonging its lifespan and ensuring efficient energy storage. Additionally, the inverter supports equalization charging, which helps maintain the battery’s performance over time.

The Growatt SPF 5000 Hybrid Inverter ES provides configurable grid or solar input priority, allowing you to prioritize charging from the grid or your connected PV system. This feature ensures that your battery receives power from the most convenient source based on your preferences or available energy.

Functions

• Integrated MPPT charger controller.
• Equalization charging function.
• Use with Batteries or without.
• Max PV input up to 450vDC.
• Choose grid or solar input priority.
• WIFI/GPRS remote monitoring.
• Parallel up to 6 inverters.
• PV & Grid Power combine if PV energy is insufficient for load.
• Flexible schedule for charging and discharging the batteries.

General Specifications

• Module: SPF 5000 ES.
• Battery voltage: 48vDC.
• Battery type: Lithium/Lead-acid.

Inverter Output [AC]

• Rated Power: 5000W.
• AC Voltage Regulation (Battery): 230VAC ± 5%.
• Surge Power: 10000VA for 5 sec.
• Efficiency (Peak): 93%.
• Waveform: Pure sine wave.
• Transfer Time: 10ms – 20ms.

Solar Charger

• Maximum PV Array Power: 6000W.
• MPPT Range @ Operating Voltage: 120VDC – 430VDC.
• Maximum PV Array Open Circuit Voltage: 450vDC.
• Maximum Solar Charge Current: 100 A.

AC Charger

• AC Charge Current: 80A.
• AC Input Voltage: 230 VAC.
• Selectable Voltage Range: 230 VAC.
• Frequency Range : 50 Hz/60 Hz (Auto sensing).

Physical

• Protection degree: IP20.
• Height: 330 x 485 x 135mm.
• Weight: 12 kg
• Warranties: 2 Years

Warranties:

All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.

PACKAGE INCLUDE

1x HYBRID GROWATT INVERTER 5KVA 48V

1x WIFI DONGLE

1x USER MANUAL
