5.12kWh DYNESS DL5.0C LiFeP04 Lithium Battery Version 2

DL5.0C 5.12kWh 51.2V LiFePO₄ Battery – Compact & Scalable Storage

1 C DYNESS LITHIUM BATTERY

Description:

Advanced Lithium Power for Modern Solar Systems
The DL5.0C LiFePO₄ battery delivers 5.12kWh of stable energy with high efficiency and robust cycle life. Engineered for residential and commercial solar storage, it supports both hybrid and off-grid applications. Its modular design enables scalable configurations for expanding energy needs.

Key Features:

High-Performance Energy Storage

-Nominal Energy Output: 5.12kWh (Version 2)

-Capacity: 100Ah

-Nominal Voltage: 51.2V

-Depth of Discharge (DOD): 90%

-Operating Voltage Range: 44.8V to 57.6V

-Cycle Life: ≥6000 cycles (0.5C at 80% DOD)

Efficient Charging & Discharging

-Recommended Charge/Discharge Current: 50A

-Max Charge Current: 75A

-Max Discharge Current: 100A

-Peak Current: 110A for 15 seconds

-C-Rate: 0.5C standard, 1C max discharge

Built for Versatility and Scale

-Supports hybrid and off-grid setups

-Expandable up to 50 units in parallel

-Compact and wall-mountable (Dimensions: 558×545×150 mm)

-Net Weight: 54kg

Smart Operation & Protection

-Communication Interfaces: CAN, RS485, RS232

-Protection Level: IP20

-Charging Temperature: 0–55°C (with heating function down to -20°C)

-Discharging Temperature: -20–55°C

Certified for Safety and Reliability

-Safety Standards: UN38.3, CE-EMC, IEC62619, CEI-021

Warranty & Installation Compliance

To qualify for warranty support, the DL5.0C battery must be installed by a registered wireman or master electrician. Installation must comply with SANS 10142 regulations and include a valid Certificate of Compliance (COC). Warranty claims require proof of compliant installation and documentation.
