11KVA JSD Solar Hybrid Inverter + 2x 5.12kWh Dyness Lithium Battery + 6x 560W TIER 1 Solar Panel Off Grid Combo
11KVA JSD Solar Hybrid Inverter + 2x 5.12kWh Dyness Lithium Battery + 6x 560W TIER 1 Solar Panel Off Grid Combo
Please note that the stock quantities displayed are for our warehouse. Please confirm stock on hand directly with us before collecting your order.
Low stock: 6 left
Couldn't load pickup availability
11KVA JSD Solar Hybrid Inverter + 2x 5.12kWh Dyness Lithium Battery + 6x 560W TIER 1 Solar Panel Off Grid Combo
Combo Includes:
1x JSD 11KVA SOLAR MPPT HYBRID INVERTER
2x 5.12KWH DYNESS VERSION 2 LITHIUM BATTERY
6x TIER 1 560W MEGATRON SOLAR PANELS
Description:
The Ecco J11000H is a high-output 48V hybrid inverter built for demanding residential and light commercial solar backup systems. It combines strong PV input capability, high-current battery charging, and flexible operating priorities to suit a wide range of installation requirements.
PV and MPPT Solar Charging
Built-in 2 MPPT trackers for efficient energy harvesting across varying roof strings
Maximum PV input voltage: 500VDC
Maximum PV array power: 5500W
MPPT operating range: 60VDC to 500VDC
High-current solar charging with a maximum charge current of 160A
Battery System and Charging Control
-Designed for 48VDC battery systems
-Maximum discharge current: 220A
-Charging method: CC/CV
-Floating charge voltage: 54VDC
-Overcharge protection: 63VDC
-Lithium battery activation function supported via PV input or utility supply
-Compatible operation with LiFePO4 batteries via RS485 communication
-EQ function supports battery performance optimisation and can help extend lifecycle
System Performance and Operating Logic
-Power factor: 1.0 for full real-power output utilisation
-Multiple output priority modes supported: UTL, SOL, SBU, SUB
-Detachable dust cover designed for harsher operating environments
Monitoring and Communications
-LCD display for system status and monitoring
-Communication interfaces: RS232, RS485, dry contact
-Optional WiFi remote monitoring available
Mechanical and Environmental
-Dimensions: 540 × 415 × 122 mm
-Weight: 15 kg
-Operating temperature range: -10°C to 50°C
DL5.0C 5.12kWh 51.2V LiFePO₄ Battery – Compact & Scalable Storage
1 C DYNESS LITHIUM BATTERY
Description:
Advanced Lithium Power for Modern Solar Systems
The DL5.0C LiFePO₄ battery delivers 5.12kWh of stable energy with high efficiency and robust cycle life. Engineered for residential and commercial solar storage, it supports both hybrid and off-grid applications. Its modular design enables scalable configurations for expanding energy needs.
Key Features:
High-Performance Energy Storage
-Nominal Energy Output: 5.12kWh (Version 2)
-Capacity: 100Ah
-Nominal Voltage: 51.2V
-Depth of Discharge (DOD): 90%
-Operating Voltage Range: 44.8V to 57.6V
-Cycle Life: ≥6000 cycles (0.5C at 80% DOD)
Efficient Charging & Discharging
-Recommended Charge/Discharge Current: 50A
-Max Charge Current: 75A
-Max Discharge Current: 100A
-Peak Current: 110A for 15 seconds
-C-Rate: 0.5C standard, 1C max discharge
Built for Versatility and Scale
-Supports hybrid and off-grid setups
-Expandable up to 50 units in parallel
-Compact and wall-mountable (Dimensions: 558×545×150 mm)
-Net Weight: 54kg
Smart Operation & Protection
-Communication Interfaces: CAN, RS485, RS232
-Protection Level: IP20
-Charging Temperature: 0–55°C (with heating function down to -20°C)
-Discharging Temperature: -20–55°C
Certified for Safety and Reliability
-Safety Standards: UN38.3, CE-EMC, IEC62619, CEI-021
Warranty and Installation Requirements
BATTERY - 7 YEAR
INVERTER - 5 YEAR
SOLAR PANELS - 15 YEAR
PLEASE NOTE THAT SOLAR PANELS ARE COURIERED AT OWN RISK
Installation should be completed by a qualified electrician and set up in accordance with SANS 10142 requirements, with a valid COC issued for the installation where applicable
Warranty support may require proof of compliant installation and commissioning information, depending on supplier terms
